Cat.6A+ Shielded Cable

product feature conform to ANSI TIA/EIA-568-B.2-10，IEEE802.3an all requirements of the standard draft A single - core double stranded cable with 23AWG，With high density foam PE(FOAMPE) insulation, and tin-plated copper mesh weaving Effective protection against EMI and rf interference (RFI) Optional PVC (PVC), LSOH (low smoke non-toxic) Range of application 10/100base-t Ethernet (IEEE802.3) 1000base-tx gigabit Ethernet (IEEE802.3 ab) 155 Mbps ATM network 100 vg - AnyLAN (IEEE802.12) TP - PMD (ANSI X3T9. 5) 16 Mbps Token Ring Token network (IEEE802.5) ISDN integrated business data network Product certification Through UL, ETL,3P certification

Cat.6A+ Shielded Keystone Jack

ULIPUL 180 ° 6 a + die-cast block module is a new upgrade design, can be fully implemented in 2010 released component standard ISO/IEC 11801 AMD: 2. The additional 30% permanent link net balance ensures a relatively traditional 6A link product, and is also the best option to support IEEE 802.3an 10G application. Product features Comply with TIA/EIA- 568c.2, ISO/IEC 11801 AMD2:2010-04, ISO/IEC 60603-7-51 and EN 50173-1 Class EA standard. The die casting grinder is designed to achieve optimal EMI protection. Ultra-thin size makes space compact and interface ideal. Channel requirements for short link performance of ISO/IEC 11801 and EN 50173. Multi-node consolidation line, reliable end-to-end solution and high data traffic applications. The compact design and standard size of the finished product are suitable for global types of sockets. A data center or cross-connection of a modular terminal block compatible with a high quality line. Free shearing connection to avoid cable splicing in each case. Comply with RoHS standards. Range of application 10 gbase -t Ethernet 1000base-tx precursor Ethernet 1000base-t precursor Ethernet 100base-tx fast Ethernet 10 base-t Ethernet Voice, video, and other applications

Cat.6A+ Shielded Patch Cord

Professional 45 ° Angle involved, reduce cable weight, ensure electrical characteristics, each port configuration plastic respectively to facilitate efficient port management. The icon displays the telephone system and the network system. The whole plastic frame is lighter than other distribution frame for easy construction and installation. The design of type 110 and dual-use IDC supports the 23-26awg cable. Product features Comply with the latest ANSI/TIA-568- c.2, ISO/IEC 11801, EN 50173 standard, with a bandwidth of 500MHz. Using Foam Skin-PE insulation, 26AWG multi-core soft copper wire manufacturing, each shielding package structure, effectively prevent electromagnetic interference (EMI) and rf interference (RFI). The 50u inch gold-plated three-fork blade RJ45 crystal head ensures reliable connection between the cable and the crystal head, and the forming net tail can decompose the bending stress to guarantee the performance stability. Comply with T568B standard sequence, provide various lengths, various colors, meet the different management needs of the project wiring machine room and the client. Depending on the environment, PVC and LSOH class sheath can be selected. Range of application 10G base-t wan Ethernet 1000base-t gigabit Ethernet 100 base-t Ethernet ISDN integrated business data network Product certification Through UL, ETL, 3P certification

10G6A each pair of shielded cables

Product features Comply with all requirements of the draft standard, such as the ANSI TIA/EIA-568-B.2-10,IEEE802.3 an. A single - core double stranded cable with 23AWG is used, and the high density FOAMPE is used to insulate it, and it is plated with tin copper mesh, which can effectively prevent EMI and rf interference (RFI). Optional PVC (PVC), LSOH (low smoke non-toxic) Application range 10/100base-t Ethernet (IEEE802.3) 1000base-tx gigabit Ethernet (IEEE802.3 ab) 155 MBPS ATM networks 100 vg - AnyLAN (IEEE802.12) TP - PMD (ANSI X3T9. 5) 16 Mbps Token Ring Token network (IEEE802.5) ISDN integrated business data network Product certification Through UL,ETL,3P certification

10G6A Wiring frame

Product features 12,24 modular distribution frames can be provided. Snap-in is designed for various class modules. The modular card is easy to connect, with high performance and easy to operate. You can install the EIA 19-inch standard frame. Deluxe type with dust cover. Otherwise, it is easy to identify and manage the cables. Application range 10 base-t Ethernet 100base-tx Fast Ethernet 1000base-t Fast Ethernet Analog and digital voice (VoIP) Analog and digital video Execution standard To ISO/iec11801and EN50173-1

10G Cat.6A+ Unshielded Modular

Product features The 10G base-t Ethernet system can be supported within 100 meters and fully backward compatible. Meet and exceed the requirements of the ANSI/tia-58-b. 2-10, ISO/IEC 11801 standard, and the bandwidth reaches 500MHz. High impact PC engineering plastics, suitable for different application environments; . IDC reed and PCB board adopt cold - pressing process to ensure reliable contact. The contact needle can withstand up to 750 insertion, and the IDC terminal can hold up to 250 compression. Non-blocking modules provide a variety of colors. Application range 10 base-t / 100 Base - Tx / 100 Base - T4/1000 base-t Base - Tx / 10 g ATM/ATM - 155/100-25 / ATM - 51 vg - AnyLan TR - 4 / TR - 16 Active/TR16 Passive
